Hulled Sesame,Raw Sesame,Black and Withe Sesame Color Sorter
Basic situation of Seed Color Sorter
The Seed Color Sorter is based on differences in the optical properties of Seed. It uses photoelectric technology to scan the particles of the Seed and sort it automatically, so as to improve its quality and remove any defect or contamination.
1. Raw Material are put into the machine from its feeding hopper on the top.
2. Vibrated by vibration device and sliding along material chute into the zone of observation in sorting chamber through sensor and background plate .
3. Under the effect of light source, CCD sensor receives compound light from materials being sorted.
4. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.
Technical Parameter
| Model | 6SXM-256JM4 |
| Output(T/h) | 2-3 |
| Carryover Rate(Bad:Good) | >15:1 |
| Sorting Accuracy(%) | ≥99.9 |
| Voltage (V/Hz) | 220V 50HZ |
| Power Supply(Kw) | ≤2.6 |
| Pressure(Mpa) | 0.5-0.8 |
| Weight(Kg) | 1200(±5%) |
| Diamension(mm) | 1800*1620*2040 |
Company Advantage
1. Over many years experiences focus on color sorter. The one of a leading sorter machine factory in south China. We have the strength give better service and price to you.
2. Overseas Service Station: We have service station, cooperate reseller more than 40 countries. Wesort can meet your requirements on testing, installation and after sales service.
3. OEM/ODM is Supported: We have a strong R&G team(5 famous doctor engineers are included ). We can research and development suitable color sorter for you.
4. Quality Process Assurance: We pass ISO quality management system, each process of production are under strictly standard.
5. Shipping Guarantee: we have professional packaging operations team, independent export qualification to ensure product safety and stability to reach customers in the hands.
6. After-sales Service Guarantee: We provide one year warranty and lifetime maintenance. Free home repair during the warranty period (except for human factors or irresistible natural phenomena caused by failure or damage)
7. Sales team: Our professional sales team is fluent in English, Russian, Chinese , Spanish and Japanese. Can communicate better with customers.
